What is the rough opening for a roll up door

The rough opening for a roll up door is typically depend on the specific dimensions of the door you intend to install. For a roll-up door, the rough opening size typically needs to be slightly larger than the door itself to accommodate the tracks, rollers, and necessary clearance for installation and operation.

What is the rough opening for a roll up door

A common rough opening size for a 10×10 roll-up door is around 10 feet 4 inches (3.15 meters) in width and 10 feet 2 inches (3.1 meters) in height. These measurements allow for the proper installation and function of the roll-up door system.

A roll-up door is a type of door commonly used in commercial and industrial settings. It consists of horizontal slats that are connected and rolled around a drum above the doorway. Roll-up doors are popular because they save space, provide security, and are durable enough to withstand heavy usage. They’re often seen in warehouses, storage facilities, garages, and storefronts.

The standard size of a roll up door includes: 10×10 (10′ wide by 10′ high), 12×12 (12′ wide by 12′ high), 10×12 (10′ wide by 12′ high), 10×8 (10′ wide by 8′ high), 12×14 (12′ wide by 14′ high), 8×8 (8′ wide by 8′ high), 8×7 (8′ wide by 7′ high), 7×7 (7′ wide by 7′ high), and 9×7 (9′ wide by 7′ high).

The Roll Up Door Rough Opening (RO) is the size of the door opening before the finished rails, the rollers, have been attached to the posts. For a roll-up door, the rough opening should be 4 inches wider than the width of the door, measured between the left and right edges, and 2 inches taller than the height of your new door.

Here’s are the rough opening size for a different roll up door size:

  1. The rough opening size for a 10×10 (10′ wide by 10′ high) roll-up door is around 10 feet 4 inches in width and 10 feet 2 inches in height.
  2. The rough opening size for a 12×12 (12′ wide by 12′ high) roll-up door is around 12 feet 4 inches in width and 12 feet 2 inches in height.
  3. The rough opening size for a 10×12 (10′ wide by 12′ high) roll-up door is around 10 feet 4 inches in width and 12 feet 2 inches in height.
  4. The rough opening size for a 12×14 (12′ wide by 14′ high) roll-up door is around 12 feet 4 inches in width and 14 feet 2 inches in height.
  5. The rough opening size for a 10×8 (10′ wide by 8′ high) roll-up door is around 10 feet 4 inches in width and 8 feet 2 inches in height.
  6. The rough opening size for a 8×8 (8′ wide by 8′ high) roll-up door is around 8 feet 4 inches in width and 8 feet 2 inches in height.
  7. The rough opening size for a 8×7 (8′ wide by 7′ high) roll-up door is around 8 feet 4 inches in width and 7 feet 2 inches in height.
  8. The rough opening size for a 7×7 (7′ wide by 7′ high) roll-up door is around 7 feet 4 inches in width and 7 feet 2 inches in height.
  9. The rough opening size for a 9×7 (9′ wide by 7′ high) roll-up door is around 9 feet 4 inches in width and 7 feet 2 inches in height.
  10. The rough opening size for a 6×7 (6′ wide by 7′ high) roll-up door is around 6 feet 4 inches in width and 7 feet 2 inches in height.

You will need at least 15 inches and 23 inches clearance as a headroom for the top height of the header for installing the roll up door. Here’s are table for rough opening size for different roll up door-

ROLL UP DOOR SIZEROUGH OPENING SIZE
10 X 1010′ 4″ X 10′ 2″
10 X 1210′ 4″ X 12′ 2″
12 X 1212′ 4″ X 12′ 2″
12 X 1412′ 4″ X 14′ 2″
10 X 810′ 4″ X 8′ 2″
8 X 88′ 4″ X 8′ 2″
 8 X 78′ 4″ X 7′ 2″
7 X 77′ 4″ X 7′ 2″
9 X 79′ 4″ X 7′ 2″
6 X 76′ 4″ X 7′ 2″

Conclusions:-
The Rough opening size for a roll up door should be 4 inches wider than the door width and 2 inches taller than your new door’s height. So, for a 10×10 roll up door, the rough opening should be 10 feet 4 inches in width and 10 feet 2 inches in height.
