Minimum & standard concrete slab thickness for office building, Hi guys in this article we know about slab thickness for office building | minimum concrete slab thickness for office building | maximum concrete slab thickness for office building | standard concrete slab thickness for office building | nominal slab thickness for office building | slab thickness for office building as per IS code 456: 2000.
Determine the thickness of slab for office building, concrete floor structure first you should to figure out total load ,what kind of concrete slab you have needed, it is concentrated load or spread load all over the slab, there is a different rules for finding the thickness of slab for office building structure.
◆You Can Follow me on Facebook and Subscribe our Youtube Channel
You should also visits:-
1)what is concrete and its types and properties
2) concrete quantity calculation for staircase and its formula
Construction structure concrete slab needs proper designs, grade of Steel, grade of concrete should be used to poured the concrete to make the floor slab. If you are confusing with acting load it is light medium or heavy take the help of architectural engineer better to calculate and make design of floor slab according to the load and span of floor slab.
You know that thickness of concrete floor slab depends on load acting on it and its span, whether it is concentrated load or is spread all over the slab, type of construction structure.
According to loading condition on concrete floor slab and their span, there is a choice to choose thickness of floor slab as proper design, but in this article using some basic thumb rules, regulation and guideline as per ACI code and IS code 456:2000 to find out minimum and standard thickness of concrete slab for office building.
Minimum & standard concrete slab thickness for office building
Concrete slab thickness for office building depends on material, Engineering, load acting on it and span, it need proper design, what kind of material should be used, concreting material, Steels and other materials resist environmental factor, good and sound floor slab should be needed.
Slab thickness for office building:- using some basic thumb rules, regulation and guideline as per ACI code and IS code 456:2000, for concrete floor, concrete slab thickness for office building is kept 8 inch to 10″ (200mm to 250mm), providing minimum concrete grade M10 to M15 and mesh bar embedded in concrete, 2″ deep from top of floor slab.
Minimum slab thickness for office building:- using some basic thumb rules, regulation and guideline as per ACI code and IS code 456:2000, for concrete floor, minimum concrete slab thickness for office building is kept 8 inch (200mm), providing minimum concrete grade M10 to M15 and mesh bar should be embedded in concrete, 2″ deep from top of floor slab.
Maximum slab thickness for office building:– using some basic thumb rules, regulation and guideline as per ACI code and IS code 456:2000, for concrete floor, maximum concrete slab thickness for office building is kept 10 inch (250mm), providing maximum concrete grade M10 to M20 and mesh bar should be embedded in concrete, 2″ deep from top of floor slab.
Standard slab thickness for office building:- there is no standard thickness mention in IS Code, but using some basic thumb rules, regulation and guideline, I recommend to use for concrete floor, standard concrete slab thickness for office building is kept 10 inch (250mm) thick, providing standard concrete grade M10 to M20 and mesh bar should be embedded in concrete, 2″ deep from top of floor slab.
Nominal slab thickness for office building:– there is no nominal thickness mention in IS Code, but using some basic thumb rules, regulation and guideline, I recommend to use for concrete floor, nominal concrete slab thickness for office building is kept 8″ to 10 inch (200mm to 250mm) thick, providing nominal mix concrete grade M10 to M20 and mesh bar should be embedded in concrete, 2″ deep from top of floor slab.
How thick should be a Slab be for a office building? using some basic thumb rules, regulation and guideline as per ACI code and IS code 456:2000, for concrete floor, It should be 8″ to 10″ (200mm to 250mm) thick concrete slab for office building, providing minimum concrete grade M10 to M15 and mesh bar embedded in concrete, 2″ deep from top of floor slab.
