The appropriate size of laminated veneer lumber (LVL) needed to span 26 feet will depend on various factors, including the load it needs to support, construction requirements, species and grade of wood and the spacing between supports and a local building code.
To determine the appropriate size of LVL (Laminated Veneer Lumber) to span 26 feet, you will need to consider various factors. However, as per rough guideline, for residential construction, a common choice for spanning 26 feet might be an LVL with dimensions around 5-1/4″ inches by 14-16″ inches.
Laminated veneer lumber or LVL is much look like plywood, generally made of thin sheets of wood which are sandwiched and bound with super stronger glue. It is a high-strength structural engineered wood product of recent innovation and one of the most widely used kinds of lumber in construction projects in. It is typically used for boards of all kinds, for headers, beam rim boards, skateboards, as well as beams, trusses, edge forming materials and more. It is available in a wide range of lengths, widths and thicknesses.
The American wood Council National design specification for wood, lvl is type of structural composite lumber comparable to glued laminated timber (glulam). LVL is product of recent innovation they are result of new technology and economic pressure to make use of new wood species and smaller trees that cannot be used to make solid Lumber.
LVL is a straight, enough strong wood that fights warping and shrinking, providing great stability for your projects. Use an LVL beam to eliminate twisting and splitting for quiet floors. Because of the wood’s dimensional stability, inspection times are often reduced, too. LVL has a “maximum allowable bending stress” of 2,800 or 3,000 psi. LVL offer several advantages over technical milled lumber, it is made in factory under control specification and it is more stronger straighter and more uniform in size.
◆You Can Follow me on Facebook and
Subscribe our Youtube Channel
Lvl sizes may vary according to manufacturer but lvl standard thickness are 1 3/4 inches to 3 1/2 inches. It is available in thickness from 19mm (3/4 inches) to 178mm (7 inches). LVL length are generally available in 24, 28, 32, 36, 40 and 44 feet with special order up to 60 Feet. It can be customized according to your requirement. More than 60 Feet there is difficulty in transportation and handling.
ALSO READ :- What size lvl to span 30 feet
LVL beam depth are typically 5 1/2 inches (140mm), 7 1/4 inches (184mm), 9 1/4 inches (235mm), 9 1/2 inches (241mm), 11 1/4 inches (286mm), 11 7/8 inches (302mm), 14 inches (356mm), 16 inches (406mm), 18 inches (457mm), 18 3/4 inches (476mm), 20 inches (508mm) and 23 7/8 inches (606mm).
What size lvl beam do i need to span 26 feet
As per LVL span rule of thumb, the depth of the LVL beam is about 1/20th of span in inches and their width is 1/3 to 1/4 of the depth. If beam span is 26 feet in length, then their depth = (26 × 12) ÷ 20 = approx 16 inches and width is 16/3 = approx 6″. So, you would need something like 5 1/2″ × 16″ size of LVL beam for a 26 foot span.
What size lvl beam for a 26 foot span
Typically for a 26 foot span, size of LVL (Laminated veneer lumber) beam need to be 14-16 inches deep and 6 inches wide. So you would need something like a 5 1/4″× 14″ or 5-1/4×16″ LVL or engineered wood to span upto 26 feet used for residential application on normal weight condition.
26 ft lvl beam price
The price of LVL (Laminated veneer lumber) is around $3 to $12 per linear foot. So, for 26 ft lvl beam price = 26×3 = $78 or 26×12 = $312. So, the cost of 26 ft lVL beam or Laminated veneer lumber or Engineered beam would be range between $78 to $312 for materials or between $50 to $200 per foot for installation.
◆You Can Follow me on Facebook and
Subscribe our Youtube Channel
What size lvl to span 26 feet
The size of the LVL (Laminated Veneer Lumber) needed to span 26 feet need to be 14-16 inches deep and 5-1/4 inches wide. So you would need something like a 5 1/4″× 14″ or 5-1/4×16″ LVL or engineered wood to span upto 26 feet
ALSO READ :- What size lvl to span 30 feet
Conclusions:-
Typically for span a 26 foot span, you would need 5-1/4″ × 14″ size of LVL beam or engineered wood on normal weight condition which providing great stability for your projects.
