Foundation depth in rocky soil | Good foundation in rocky soil

Foundation depth in rocky soil | Good foundation in rocky soil, hi guys in this article we know about which type of foundation is used in rocky soil | minimum depth of foundation in rocky soil | maximum depth of foundation in rocky soil | Foundation depth for Rocky soil.

Really it is hard task to build a new house on rock, it is quite expensive for making holes in rock for Foundation. When we start our new project there is necessary to preliminary work is to layout Foundation. If houses build on rock it is quite difficult and not easy task to dig out soil in rock.

Hard strata of rock have a strong soil bearing capacity, quite stable and more durable. It has strong bearing capacity, it can provide structural support without any shrinkage or swelling. Hard rocks is made of igneous and metamorphic rocks like granite and basalt. It is distinguished from sedimentary rocks because they are typically more difficult to broken. Safe bearing capacity of hard rock like Granite and basalt is about 33kg/cm2 (3300kN/m2).

Foundation depth in rocky soil | Good foundation in rocky soil
Foundation depth in rocky soil | Good foundation in rocky soil

Can you build house on solid rock? It’s not too hard to build a home on solid rock. Make digging in rocky soil is not easy task, it need to be blast when when excavators can dig through your rock. The biggest thing you need to understand is the relationship between water and rock. Rainwater penetrates topsoil and starts to head into the ground. The shallow storage takes place in weathered hard rocks that occur at shallow depth that may be harmful for your Foundation. So if you build a house on Rocky soil then proper drainage system beneath the soil is required.

◆You Can Follow me on Facebook and Subscribe our Youtube Channel

You should also visits:-

1)what is concrete and its types and properties

2) concrete quantity calculation for staircase and its formula

Issue of soft Rock causing problem in foundation:- Water present on earth seep into the ground in the direction of gravity. The rock below the Earth’s surface is the bedrock. If all bedrock consisted of a dense material like solid granite, then even gravity would have a hard time pulling water downward. But Earth’s bedrock consists of many types of rock, such as sandstone, granite, and limestone. Bedrocks have varying amounts of void spaces in them where groundwater accumulates. Bedrock can also become broken and fractured, creating spaces that can fill with water. And some bedrock, such as limestone, are dissolved by water — which results in large cavities that fill with water.

Underground storage of water below the rocky soil is harmful for your Foundation of footing that eroded the concrete face of footing and making cavity causing crack in foundation,that is major problem when you build a house on rocky soil. Make sure about water does not touch your Foundation,So if you build a house on Rocky soil then proper drainage system beneath the soil is required.

Foundation depth in rocky soil | Good foundation type in rocky soil

IS 12070 (1987) Bureau of Indian standard BIS code of practice for design and construction of Shallow Foundation on Rock in civil engineering section of rock mechanics.

A foundation/footing is a lower portion of building structure or substructure that transfers its all coming loads of structure to the ground. The design of size and depth of foundation depends on the total load on the building and the type of sub soil and its bearing capacity.

Foundations are generally broken into two categories mainly, shallow foundations and deep foundations.

Foundation with depth less than 3 meter are shallow foundations. Such foundations are used for structures that do not carry much load. They are also used in case the soil has high bearing capacity. Examples of Shallow Foundation is isolated footing, combined footing, strap footing and raft footing.

Foundations with depth greater than 3 meter are deep foundations. They are deep below the finished ground surface such that their base bearing capacity is not affected by surface conditions. Examples of deep Foundation is Pile and piers formation.

What is the minimum depth of foundation in rocky soil/mountain? If footing of foundation of your building built on the rock/mountain. As per Indian Standards, minimum depth of foundation shall be 0.5m (500mm or 1.64 foot),if shallow foundation is preffered

What is the maximum depth of foundation in rocky soil? If footing of foundation of your building built on the rock. As per Indian Standards, maximum depth of foundation shall be 1.5m (1500mm or 5 foot) if shallow foundation is preffered.

Foundation depth in rocky soil:– The Revised Edition of IRC:78 “Standard Specifications and Code of Practice for Road. Bridges” Section VII – Foundation, As per IRC-78, rocks having ultimate compressive strength (UCS) is less than 12.5MPa and greater 2.5MPa, minimum depth of foundation embedment in the rocky soil shall be 1.5m (1500mm or 5 foot). For rocks having ultimate compressive strength (UCS) greater than 12.5MPa, minimum depth of foundation embedment in rocky soil shall be 0.6m (600mm or 2 foot).

Which type of foundation is used in rocky soil? Foundation built on rock have good water drainage system under the ground, Rocks such as igneous and Metamorphic rock like limestone, granite, sandstone and hard solid chalk have a high bearing capacity. When the soil is rocky with high bearing capacity, then shallow foundation of strap footing is good and work well. Depth of foundation in rocky soil less than 0.7meter.
