What is the standard size of a cement concrete block

The standard size of a cement concrete block can vary, but a common size is 8 inches by 8 inches by 16 inches. This size is widely used in construction for building walls and other structural elements.

Concrete masonry unit in short form represented as CMU made of concrete, mixture of cement, sand and water. There is a form of concrete masonry unit concrete block, concrete bricks, hollow concrete block, solid concrete block, lintel block, concrete stretcher block, concrete pillar blocks, partition concrete block, corner concrete block, concrete pillar block.

What is the standard size of a cement concrete block
What is the standard size of a cement concrete block

Concrete block serve as economic building material and there is a wide range of Construction application for many types of Residential, Public and industrial building. Due to sturdy and long lasting building material, architect and Engineer will recommended for house construction, retaining wall, security barriers etc and this is best choice.

◆You Can Follow me on Facebook and Subscribe our Youtube Channel

You should also visits:-

1)what is concrete and its types and properties

2) concrete quantity calculation for staircase and its formula

Whether you are planning to construct project, renovate your house, better choice is to use concrete block as construction material to lay out external or partition wall.

Concrete block is highly adaptable and versatile material resistance of fire, variety of aesthetic qualities, high structural capacity, strength, longevity, beautiful appearance, resistant to water, need minimum maintenance and economical building material, due to this it is widely used all over the world.

For the most part, in the US, we don’t use bricks to build houses or business buildings any more. smart people invented precast concrete structural unit/ modules, also known as concrete blocks used for various type of project like Residential Public building and industrial building.

What is the standard size of a cement concrete block

In many part of world, widely used in India, US, UK and other countries, concrete Masonry Units (CMUs) are manufactured in a variety of sizes. But most common, nominal size of concrete block used is 4″, 6″, 8″, 10″ and 12″ CMU full/ half block. They are identified by their depth or by their thickness of the wall they create. For instance, a 6″ CMU is nominally 6″ or 150mm deep while a 10″ CMU is nominally 10″ or 250mm deep.

Standard dimensions of concrete block

The standard dimensions for most concrete blocks are (L x H x W): 8 inches (16 x 8 x 8 inches). However, these dimensions include the length of the average mortar joint, which is 3/8 inch.

Standard sizes of concrete block

The standard sizes for most concrete blocks are (L x H x W): 8 inches (16 x 8 x 8 inches). However, these sizes include the length of the average mortar joint, which is 3/8 inch.

Nominal size of concrete block

Standard concrete block masonry units are commonly comes in nominal length of 400 mm, height of 200 mm and widths of 100 mm, 150, 200, 250, and 300 mm.

Actual size of concrete block

Standard concrete block masonry units are commonly comes in actual length of 390 mm, height of 190 mm and widths of 90 mm, 140, 190, 240, and 290 mm.

4″ concrete block size/dimensions

Typical nominal sizes (dimensions) for standard 4″ full concrete blocks are (L × H × W): 16 × 8 × 4 inch (or 400 × 200 × 100 mm) and 4″ half concrete blocks are 8 × 8 × 4 inch (or 200 × 200 × 100 mm).

Typical actual sizes (dimensions) of standard 4″ full concrete blocks are (L × H × W): 15 5/8″ × 7 5/8″ × 3 5/8″ (or 390 × 190 × 90 mm) and 4″ half concrete blocks are 7 5/8″ × 7 5/8″ × 3 5/8″ (or 190 × 190 × 90 mm).

5″ concrete block size/dimensions

Typical nominal sizes (dimensions) for standard 5″ full concrete blocks are (L × H × W): 16 × 8 × 5 inch (or 400 × 200 × 125 mm) and 5″ half concrete blocks are 8 × 8 × 5 inch (or 200 × 200 × 125 mm).

Typical actual sizes (dimensions) of standard 5″ full concrete blocks are (L × H × W): 15 5/8″ × 7 5/8″ × 4 5/8″ (or 390 × 190 × 115 mm) and 5″ half concrete blocks are 7 5/8″ × 7 5/8″ × 4 5/8″ (or 190 × 190 × 115 mm).

6″ concrete block size/dimensions

Typical nominal sizes (dimensions) for standard 6″ full concrete blocks are (L × H × W): 16 × 8 × 6 inch (or 400 × 200 × 150 mm) and 6″ half concrete blocks are 8 × 8 × 6 inch (or 200 × 200 × 150 mm).

Typical actual sizes (dimensions) of standard 6″ full concrete blocks are (L × H × W): 15 5/8″ × 7 5/8″ × 5 5/8″ (or 390 × 190 × 140 mm) and 6″ half concrete blocks are 7 5/8″ × 7 5/8″ × 5 5/8″ (or 190 × 190 × 140 mm).

8″ concrete block size/dimensions

Typical nominal sizes (dimensions) for standard 8″ full concrete blocks are (L × H × W): 16 × 8 × 8 inch (or 400 × 200 × 200 mm) and 8″ half concrete blocks are 8 × 8 × 8 inch (or 200 × 200 × 200 mm).

Typical actual sizes (dimensions) of standard 8″ full concrete blocks are (L × H × W): 15 5/8″ × 7 5/8″ × 7 5/8″ (or 390 × 190 × 190 mm) and 8″ half concrete blocks are 7 5/8″ × 7 5/8″ × 7 5/8″ (or 190 × 190 × 190 mm).

10″ concrete block size/dimensions

Typical nominal sizes (dimensions) for standard 10″ full concrete blocks are (L × H × W): 16 × 8 × 10 inch (or 400 × 200 × 250 mm) and 10″ half concrete blocks are 8 × 8 × 10 inch (or 200 × 200 × 250 mm).

Typical actual sizes (dimensions) of standard 10″ full concrete blocks are (L × H × W): 15 5/8″ × 7 5/8″ × 9 5/8″ (or 390 × 190 × 240 mm) and 10″ half concrete blocks are 7 5/8″ × 7 5/8″ × 9 5/8″ (or 190 × 190 × 240 mm).

12″ concrete block size/dimensions

Typical nominal sizes (dimensions) for standard 12″ full concrete blocks are (L × H × W): 16 × 8 × 12 inch (or 400 × 200 × 300 mm) and 12″ half concrete blocks are 8 × 8 × 12 inch (or 200 × 200 × 300 mm).

Typical actual sizes (dimensions) of standard 12″ full concrete blocks are (L × H × W): 15 5/8″ × 7 5/8″ × 11 5/8″ (or 390 × 190 × 290 mm) and 12″ half concrete blocks are 7 5/8″ × 7 5/8″ × 11 5/8″ (or 190 × 190 × 290 mm).

Concrete block size in mm

Standard sizes of concrete blocks are 400 mm long, 200 mm high, and 100 to 300 mm thick. Common nominal sizes of standard concrete blocks in mm are (L×H×B): 400 × 200 × 75, 400 × 200 × 100, 400 × 200 × 125, 400 × 200 × 150, 400 × 200 × 200, 400 × 200 × 230, 400 × 200 × 250, and 400 × 200 × 300. This is ideal, best, commonly used, normal and standard size of concrete blocks in mm.

Concrete block size in cm

Standard sizes of concrete blocks are 40 cm long, 20 cm high, and 10 to 30 cm thick. Common nominal sizes of standard concrete blocks in cm are (L×H×B): 40 × 20 × 7.5, 40 × 20 × 10, 40 × 20 × 12.5, 40 × 20 × 15, 40 × 20 × 20, 40 × 20 × 23, 40 × 20 × 25, and 40 × 20 × 30. This is ideal, best, commonly used, normal and standard size of concrete blocks in cm.

Concrete block size in meter

Standard sizes of concrete blocks are 0.40 meters long, 0.20 meters high, and 0.10 to 0.30 meters thick. Common nominal sizes of standard concrete blocks in meter are (L×H×B): 0.4 × 0.2 × 0.075, 0.4 × 0.2 × 0.1, 0.4 × 0.2 × 0.125, 0.4 × 0.2 × 0.15, 0.4 × 0.2 × 0.2, 0.4 × 0.2 × 0.23, 0.4 × 0.2 × 0.25, and 0.4 × 0.2 × 0.3. This is ideal, best, commonly used, normal and standard size of concrete blocks in meter.

Concrete block size in inches

Standard sizes of concrete blocks are 16 inches long, 8 inches high, and 3 to 12 inches thick. Common nominal sizes of standard concrete blocks in inches are (L×H×B): 16 × 8 × 3, 16 × 8 × 4, 16 × 8 × 5, 16 × 8 × 6, 16 × 8 × 8, 16 × 8 × 9, 16 × 8 × 10, and 16 × 8 × 12. This is ideal, best, commonly used, normal and standard size of concrete blocks in inches.

Concrete block size in feet

Standard sizes of concrete blocks are 1.33 feet long, 0.66 feet high, and 0.25 to 1 feet thick. Common nominal sizes of standard concrete blocks in feet are (L×H×B): 1.33 × 0.66 × 0.25, 1.33 × 0.66 × 0.33, 1.33 × 0.66 × 0.416, 1.33 × 0.66 × 0.5, 1.33 × 0.66 × 0.66, 1.33 × 0.66 × 0.75, 1.33 × 0.66 × 0.83, and 1.33 × 0.66 × 1. This is ideal, best, commonly used, normal and standard size of concrete blocks in feet.

In some part of India, concrete blocks or concrete bricks are used in replacement of red clay brick due to economic and point of view, because bricks are so expensive and labor intensive that it makes good sense to not use them for building walls when other products like concrete are cheaper, faster, and better for building.

2D and 3D Ghar ka Naksha banane ke liye sampark kare
2D and 3D Ghar ka Naksha banane ke liye sampark kare

Concrete blocks come in Full and half-sizes, their half size is also available which are helpful in reducing the need to cut blocks in the field at corners or the end of walls. The architect should always attempt to design buildings using the nominal dimensions to the nearest half-block size to reduce waste and labor due to cut blocks.

Concrete block found in many shaped and size it may be solid or hollow, hollow concrete block have void known as core to reduce the weight of concrete block. Some hollow concrete block have two or three multiple Voids.

What is the size of solid concrete block

The standard sizes for most solid concrete blocks are (L x H x W): 8 inches (16 x 8 x 8 inches). However, these sizes include the length of the average mortar joint, which is 3/8 inch.

Typical nominal sizes (dimensions) for standard 4″ full solid concrete blocks are (L × H × W): 16 × 8 × 4 inch (or 400 × 200 × 100 mm) and 4″ half concrete blocks are 8 × 8 × 4 inch (or 200 × 200 × 100 mm).

In India, most commonly used, rectangular, standard size of solid concrete block is 4″, 6″ and 8″ thick CMU ( concrete Masonry unit), they are identified by their depth or by their thickness of the wall they create.

ALSO READ :-

Size of cinder block based on ASTM standard (4″, 6″, 8″, 10″ & 12″)

How much do cinder blocks weight (4″, 6″, 8″, 10″ & 12″)

How much does a concrete block weight (4″, 6″, 8″, 10″ & 12″)

Compressive strength of concrete block in N/mm2 and Kg/cm2

Block wall calculation | Find how many blocks you need

Standard size of concrete block used in India

There is two types of size used for concrete block:- 1) nominal or standard size and 2) actual size. Nominal size is represented as size of concrete block addition with mortar thickness, and their actual size is kept less than 3/8 inch or 9.5mm than nominal size to allow mortar joints between blocks.

In india, the standard sizes for most solid concrete locks are (L x H x W): 8 inches (16 x 8 x 8 inches) or 200 mm (400 × 200 × 200 mm). However, 4″ CMU, 6″ CMU, 10″ CMU & 12″ CMU are also used. These sizes include the length of the average mortar joint, which is 3/8 inch.

Standard/ nominal/ ideal/ perfect/ best size of concrete block used in India are following:-

4″ solid CMU:- Typical nominal sizes (dimensions) for standard 4″ full solid concrete blocks are (L × H × W): 16 × 8 × 4 inch (or 400 × 200 × 100 mm) and their actual sizes are 15 5/8″ × 7 5/8″ × 3 5/8″ (or 400 × 200 × 90 mm).

6″ solid CMU:- Typical nominal sizes (dimensions) for standard 6″ full solid concrete blocks are (L × H × W): 16 × 8 × 6 inch (or 400 × 200 × 150 mm) and their actual sizes are 15 5/8″ × 7 5/8″ × 5 5/8″ (or 400 × 200 × 140 mm).

8″ solid CMU:- Typical nominal sizes (dimensions) for standard 8″ full solid concrete blocks are (L × H × W): 16 × 8 × 8 inch (or 400 × 200 × 200 mm) and their actual sizes are 15 5/8″ × 7 5/8″ × 7 5/8″ (or 400 × 200 × 290 mm).

◆You Can Follow me on Facebook and

Subscribe our Youtube Channel

What is the size of Hollow concrete block

In many part of world, India, United Kingdom, United States, Canada, Ireland, New Zealand, Australia and other countries, many types and different size and shape of concrete Blocks are widely used as construction material for building load bearing wall, retaining wall, security barrier, external and internal wall for residential, public and industrial buildings and for other purpose.

Hollow block size in feet:- The standard size for most 2 cored hollow cinder block is (L x H x W): 0.66 feet (1.33 × 0.66 × 0.66 feet, or 16 x 8 x 8 inches) or 200 mm (400 × 200 × 200 mm). However, 0.33 feet CMU, 0.5 feet CMU, 0.83 feet CMU & 1 feet CMU are also used.

Hollow block size in inches:- The standard size for most 2 cored hollow cinder block is (L x H x W): 8 inch (16 x 8 x 8 inches, or 1.33 × 0.66 × 0.66 feet) or 200 mm (400 × 200 × 200 mm). However, 4″ feet CMU, 6″ feet CMU, 8″ feet CMU & 12″ CMU are also used.

In United States (US), the standard sizes for most 2 cored hollow cinder blocks are (L x H x W): 8 inches (16 x 8 x 8 inches) or 200 mm (400 × 200 × 200 mm). However, 4″ CMU, 6″ CMU, 10″ CMU & 12″ CMU are also used.

In Ireland and United Kingdom (UK), the standard sizes for most hollow concrete (breeze) blocks are (L x H x W): 100 mm (440 × 215 × 100 mm). However, 4″ CMU, 6″ CMU, 10″ CMU & 12″ CMU are also being used.

In Philippines, the standard sizes for most concrete solid blocks (CMU) are (L x H x W): 4 inches (16 x 8 x 4 inches) or 100 mm (400 × 200 × 100 mm). However, 8″ CMU, 6″ CMU, 10″ CMU & 12″ CMU are also used. Their actual size is kept less than 3/8 inch or 9.5mm than nominal size to allow mortar joints between blocks.

In Australia, the concrete block is also known as Besser block and Besser bricks because Besser company was major supplier of Machines that made concrete block.

In Australia, the standard sizes for most 2 cored hollow Besser block or CMU are (L x H x W): 8 inches (16 x 8 x 8 inches) or 200 mm (400 × 200 × 200 mm). However, 4″ CMU, 6″ CMU, 10″ CMU & 12″ CMU are also used.

In NewZealand, the standard sizes for most 2 cored hollow construction block or CMU are (L x H x W): 8 inches (16 x 8 x 8 inches) or 200 mm (400 × 200 × 200 mm). However, 4″ CMU, 6″ CMU, 10″ CMU & 12″ CMU are also used.

In Canada, the standard sizes for most 2 cored hollow cinder/ concrete block or CMU are (L x H x W): 8 inches (16 x 8 x 8 inches) or 200 mm (400 × 200 × 200 mm). However, 4″ CMU, 6″ CMU, 10″ CMU & 12″ CMU are also used.

ALSO READ :-

Standard width of road | standard Road Lane width

Standard pitch of roof in degrees, ratio & fraction for house

Standard size of 1BHK, 2BHK, 3BHK & 4BHK flat in India

Standard size of stairs for residential & commercial building

Standard size of window for residential building

Conclusions:-

The standard size (dimension) for a concrete block is (L x H x W): 8 inches (16 x 8 x 8 inches). However, these dimension include the length of the average mortar joint, which is 3/8 inch.
