To convert 1 ton of aggregate into cubic meters, you need to know the density of the aggregate. The density can vary depending on the type of aggregate.

1 ton 10mm 20mm & 40mm aggregate convert to m3, hi guys in this article we know about 1 ton aggregate (stone chips) weight convert into cubic metre (m3) of different size 10mm, 20mm and 40 mm. Aggregate another name is stone chips categorised into two types of fine **aggregate and coarse aggregate.**

We know that **aggregate** or gravel s consist of fine aggregate and coarse aggregate of different size 10 mm, 20 mm and 40mm (1/4″ to 2″). 10 mm size of aggregate is fine aggregate and 20 mm and 40 mm aggregate is coarse aggregate.

★ **WATCH THIS VIDEO**

**◆You Can Follow me on Facebook and Subscribe our Youtube Channel**

**You should also visits:-**

**1)what is concrete and its types and properties**

**2) concrete quantity calculation for staircase and its formula**

Aggregate or **stone chips** or gravel are used in Building, Bridge, dams Construction aggregate, or simply aggregate, is a broad category of coarse- to medium-grained particulate material used in construction, including sand, gravel, crushed stone, slag, recycled concrete and geosynthetic aggregates. Aggregates are the most mined materials in the world.

Generally **fine aggregate** consist of sand silt clay and coarse aggregate consists fine gravel medium gravel coarse gravel pebbles cobbles and boulders.

Fine aggregate having size less than 4.75 mm and coarse aggregate size ranging between more than 4.75 mm to 256 mm.

All types of aggregates measured in cubic metre and cubic feet and ton at construction site and we have know about how to convert 1 ton aggregate into cubic metre and 1 cubic metre aggregate into to kilogram and ton. Because it will be sometime sell & purchase in per ton and other in per cubic metre(m3) or CFT. sometime when we go through the interview and facing questions it will ask how 1 ton aggregate to cubic meter and also 1 ton aggregate in m3 used for billing purpose.

We know that while finding the bulk density of different types of aggregate their value is not fixed but it depends on handling how you can handle the aggregate. So density of aggregate is not fix but it ranging between 1420 kg/m3 to 1680 kg/m3.

Weight of aggregate in kilogram depends on density of aggregate and size of aggregate. Lesser dimension of aggregate have high density due to less presence of air voids & higher dimension of aggregate have lower density due to higher presence of air voids.

**Density** of 10mm, 20mm and 40mm aggregate ranging between 1420 kg/m3 to 1680 kg/m3, consider density of 10mm, 20mm & 40mm aggregate is equal to 1680 kg/m3, 1550kg/m3 & 1450 kg/m3 respectively. it means weight of 1 cubic metre of 10mm size aggregate is equal to 1680 kgs, weight of 1 cubic metre of 20mm size aggregate is equal to 1550 kgs & weight of 1 cubic metre of 40mm size aggregate is equal to 1450 kgs.

**Convert tonne to m3 aggregate**:- generally 1 tonne of aggregate equates as 1000kg and 1 m3 of aggregate weighs around 1500 kg, so covert tonne to m3 aggregate such as 1000/ 1500 = 0.66 tonnes, hence you can use aggregate tonne to m3 calculator as 1 tonne aggregate = 0.66 m3.

**Convert m3 to tonnes aggregate**:- generally 1 cubic metre of aggregate weighs around 1500 kg and 1 tonne of aggregate equates as 1000kg, so convert m3 to tonnes aggregate such as 1500/ 1000 = 1.5 tonnes, hence you can use aggregate m3 to tonnes calculator as 1m3 aggregate = 1.5 tonnes.

**20mm aggregate m3 to tonnes**:- generally 1 cubic metre of 20mm aggregate weighs around 1550 kg and 1 tonne of aggregate equates as 1000kg, so 20mm aggregate m3 to tonnes such as 1550/ 1000 = 1.55 tonnes, hence you can use 20mm aggregate m3 to tonnes calculator as 1m3 aggregate = 1.55 tonnes.

**20mm aggregate tonne to m3**:- generally 1 tonne of aggregate equates as 1000kg and 1 m3 of 20mm aggregate weighs around 1550 kg, so 20mm aggregate tonne to m3 such as 1000/ 1550 = 0.645 tonnes, hence you can use 20mm aggregate tonne to m3 calculator as 1 tonne aggregate = 0.645 m3.

**1 ton 10mm 20mm & 40mm aggregate convert to cubic meter (m3)**

1 m3 (Cubic meter) of 10mm, 20mm & 40 mm aggregate (stone) has a weight of 1,450 kg to 1,620 kg. 1 m3 of 20mm size of stone weighs about 1,550kg, 10mm about 1,620kg and 40mm about 1,450kg.

Formula to convert 1 **tonne** of 10mm, **20mm** and 40mm aggregate (stone) to m3 **(Cubic** meter**),** **Aggregate** weight **to** m3 = **Tonnes** of **Aggregate** × 0.66 m3.

**1 ton 10mm aggregate to cubic meter: **Formula to convert 1 **tonne** (ton) of 10mm aggregate (stone) to m3 **(Cubic** meter**),** **Aggregate** Volume **to** m3 = **Tonnes** of **Aggregate** × 0.60 m3. 1m3 of 10mm aggregate weighs approximately 1,680kg and 1 tonne aggregate = 1,000kg. 1 tonne 10mm aggregate to cubic meter = 1,000/1,680 = 0.60m3.

10mm aggregate or stone chips is categories as fine aggregate, dry density of 10mm aggregate = 1680 kg/m3, it means 1m3 of 10mm aggregate weight is 1680kg or 1.6ton, 1 ton = 1000kg, 1 ton 10mm aggregate or stone chips to cubic meter = 1000/1680 = 0.5950 m3,so 1 ton 10mm aggregate is equal to 0.5950 m3 (cubic meter).

**1 ton 20mm aggregate to cubic meter :**-Formula to convert 1 **tonne** (ton) of 20mm aggregate (stone) to m3 **(Cubic** meter**),** **Aggregate** Volume **to** m3 = **Tonnes** of **Aggregate** × 0.65 m3. 1m3 of 20mm aggregate weighs approximately 1,550kg and 1 tonne aggregate = 1,000kg. 1 tonne 10mm aggregate to cubic meter = 1,000/1,550 = 0.65m3.

20mm aggregate or stone chips is categories as coarse aggregate, dry density of 20mm aggregate = 1550 kg/m3, it means 1m3 of 20mm aggregate weight is 1550kg or 1.55ton, 1 ton = 1000kg, 1 ton 20mm aggregate or stone chips to cubic meter = 1000/1550 = 0.6450 m3, so 1 ton 20mm aggregate is equal to 0.6450 m3 (cubic meter).

**1 ton 40mm aggregate to cubic meter:- **Formula to convert 1 **tonne** (ton) of 40mm aggregate (stone) to m3 **(Cubic** meter**),** **Aggregate** Volume **to** m3 = **Tonnes** of **Aggregate** × 0.69 m3. 1m3 of 40mm aggregate weighs approximately 1,450kg and 1 tonne aggregate = 1,000kg. 1 tonne 40mm aggregate to cubic meter = 1,000/1,450 = 0.69m3.

40mm aggregate or stone chips is categories as coarse aggregate, dry density of 40mm aggregate = 1450 kg/m3, it means 1m3 of 40mm aggregate weight is 1450kg or 1.45ton, 1 ton = 1000kg, 1 ton 40mm aggregate or stone chips to cubic meter = 1000/1450 = 0.6896 m3,so 1 ton 40mm aggregate is equal to 0.6896 m3 (cubic meter).

**Convert m3 to tonnes aggregate calculator**

In the UK, Total Tonnes = Total m3 × 1.5. Aggregate density varies with aggregate size, so in the UK a value of 1.5 is commonly used to convert m3 of coarse aggregate to tonnes of aggregate.

**Convert tonnes to m3 aggregate calculator**

In the UK, Total m3 = Total tonnes × 0.66. Aggregate density varies with aggregate size, so in the UK a value of 0.66 is commonly used to convert tonnes of coarse aggregate to m3 of aggregate.

**Convert m3 to tonnes aggregate**

Formula to convert 1 m3 (cubic meter) of 10mm, 20mm and 40mm aggregate (stone) to tonnes**,** **Aggregate** m3 **to** tonnes = **m3** of **Aggregate** × 1.5 m3. 1m3 of 40mm aggregate weighs approximately 1,500kg and 1 tonne aggregate = 1,000kg. 1 m3 of 10mm, 20mm and 40mm aggregate to tonnes = 1,500/1,000 = 1.5 tonnes.

Convert m3 to tonnes aggregate:- Roughly 1 cubic metre of gravel or aggregate equal to 1.5 metric tonnes. Weight of aggregate may vary depending on their dry and moist condition, taking DLBD of aggregate such as 1500 kg/m3, in United Kingdom Imperial tonnes equal as 1016kg, convert m3 to tonnes aggregate such as 1500/1016 = 1.47 tonnes, so 1m3 of aggregate nearly equal to 1.5 UK tonnes.

In United States, 1 US tonnes is equal to 907 kg, convert m3 to tonnes gravel such as 1500/907 = 1.65 tonnes, so 1m3 of gravel nearly equal to 1.65 US tonnes.

In metric system 1 tonne is equal to 1000 kg, convert m3 to tonnes aggregate such as 1500/1000 = 1.5 tonnes, so 1m3 of aggregate nearly equal to 1.5 metric tonnes.

**Convert m3 to tonnes aggregate calculator**

Convert m3 to tonnes aggregate calculator you use the formula- 1m3 of aggregate = 1.65 US tonnes used in United States, or 1.5 UK tonnes in United Kingdom which is nearly equal to 1.5 metric tons in India, Australia and rest part of world.Thus, 1m3 of aggregate = 1.65 US tonnes, 1.5 UK tonnes or 1.5 metric tonnes.

**Convert m3 to tonnes sand**

Convert m3 to tonnes sand:- weight of sand may vary depending on their dry and moist condition, taking DLBD of sand such as 1600 kg/m3, in United Kingdom Imperial tonnes equal as 1016kg, convert m3 to tonnes sand such as 1600/1016 = 1.57 tonnes, so 1m3 of sand nearly equal to 1.6 UK tonnes.

In United States, 1 US tonnes is equal to 907 kg, convert m3 to tonnes sand such as 1600/907 = 1.76 tonnes, so 1m3 of sand nearly equal to 1.75 US tonnes.

In metric system 1 tonne is equal to 1000 kg, convert m3 to tonnes sand such as 1600/1000 = 1.6 tonnes, so 1m3 of sand nearly equal to 1.6 metric tonnes.

**Convert m3 to tonnes sand Calculator**

Convert m3 to tonnes sand calculator you use the formula- 1m3 of sand = 1.75 US tonnes used in United States, or 1.6 UK tonnes in United Kingdom which is nearly equal to 1.6 metric tons in India, Australia and rest part of world.Thus, 1m3 of sand = 1.75 US tonnes, 1.6 UK tonnes or 1.6 metric tonnes.

**Aggregate conversion tonnes to m3**

1 metric tonnes of aggregate is equal to 1000 kg, taking DLBD of aggregate 1500 kg/m3, aggregate conversion tonnes to m3 such as 1000/1500 = 0.66 m3, so one metric tonnes of aggregate nearly equal to 0.66m3.

In United Kingdom, 1 Imperial tonnes of aggregate is equal to 1016 kg, aggregate conversion tonnes to m3 such as 1016/1500 = 0.68 m3, so one Imperial tonnes of aggregate nearly equal to 0.68m3.

United States, 1 US tonnes of gravel is equal to 907kg, aggregate/ gravel conversion tonnes to m3 such as 907/1500 = 0.60 m3, so one US tonnes of aggregate/ gravel nearly equal to 0.60m3.

**Sand conversion tonnes to m3**

1 metric tonnes of sand is equal to 1000 kg, taking DLBD of sand 1600 kg/m3, sand conversion tonnes to m3 such as 1000/1600 = 0.63 m3, so one metric tonnes of sand nearly equal to 0.63m3.

In United Kingdom, 1 Imperial tonnes of sand is equal to 1016 kg, sand conversion tonnes to m3 such as 1016/1600 = 0.64 m3, so one Imperial tonnes of sand nearly equal to 0.64m3.

**ALSO READ :-**

**Size of aggregate used in RCC, PCC, slab, Road, Bridge & Dams**

**1m3 of concrete material cement sand aggregate and water**

**1 ton 10mm 20mm & 40mm aggregate convert to cft**

**1 ton 10mm 20mm & 40mm aggregate convert to m3**

**1 cubic meter 20 mm aggregate weight in Kg**

United States, 1 US tonnes of sand is equal to 907kg, sand conversion tonnes to m3 such as 907/1600 = 0.56 m3, so one US tonnes of sand nearly equal to 0.56m3.

**How many cubic metres in a tonne of gravel**

How many cubic meters in a tonne of gravel? There are approximately 0.5 to 0.6 cubic meters in a tonne of gravel. A cubic meter of typical dry gravel has a weight about 1,680 kilograms or 1.68 tonnes and wet gravel weighs 2002 kg, and metric tonne is 1000 kg, so number of cubic metres in a tonne of gravel = 1000÷1680 = 0.6m3 or 1000÷2000 = 0.5m3. Thus, there are 0.6 cubic meters in a tonne of dry gravel and 0.5 cubic metres in a tonne of wet gravel. A square meter of gravel with a depth of 5 cm weighs about 84 kg or 0.084 tonnes.

**How much does a cubic metre of gravel weigh**

A cubic meter of typical gravel weighs between 1,680 to 2002 kilograms or 1.68 to 2 metric tonnes. 1/4″ to 2″ (10mm, 20mm, 40mm) size of Dry gravel weighs about 1680 kg or 1.68 tonnes, wet gravel weighs about 2002 kg or 2 metric tonnes, and Gravel with natural sand weighs about 1922 kg or 1.92 metric tonnes.

Notes:- this is theoretical concept but value of aggregate or sand in m3 to tonnes or tonnes to m3 might be vary case to case. Generally sand and aggregate or gravel sold in a Jumbo or bulk bag or simply loose tonnes bag that’s volume is nearly around 0.5m3 (cubic meter).

**Conclusion:-**

Formula to convert 1 **tonne** of 10mm, **20mm** and 40mm aggregate (stone) to m3 **(Cubic** meter**),** **Aggregate** weight **to** m3 = **Tonnes** of **Aggregate** × 0.66 m3.

There are 0.5 to 0.6 cubic metres in a tonne of gravel. One tonne of dry gravel yields 0.6 m3 and wet gravel yields 0.5 m3. A cubic meter of typical dry gravel of sizes 1/4″ to 2″ weighs 1,680 kilograms or 1.68 tonnes. A cubic meter of typical wet gravel of sizes 1/4″ to 2″ weighs 2,002 kilograms or 2 metric tonnes.
