As we know that Steel are used in formation of structural member like column ,beam, footing and slab and etc of building .you know that different size of Steel bar supply by supplier having length 12 metre, how we calculate total length of Steel bar in kilogram.

Unit weight of steel

The unit weight of steel is around 7850 kg/m3 or 78.5 kN/m3 or 7.85 g/cm3 or 490 lbs/ft3 or 13231 lbs/yd3. The steel bars are majorly used as reinforcement to strengthen the concrete structures.

The typical weight of the steel is about 7,850kg (7.85 tonnes) per m3. Therefore, 1m3 of steel has an average weight of 7,850 kg (7.85 tonnes).

Steel weight per cubic inch:- Steel weighs 0.2833 pound per cubic inch. So, a 1″ square piece of steel 1 foot long weighs (1 X 1 X 12 X .283) or about 3.4 pounds.To get the weight of a steel bar, we need to calculate its volume in cubic inches.

How much does cubic inch of steel weigh:- Steel weighs 0.2833 pound per cubic inch. So, a 1″ square piece of steel 1 foot long weighs (1 X 1 X 12 X .283) or about 3.4 pounds.

0.2833 Pound is the weight of steel per cubic inch. So, a 1″ square piece of steel 1 foot long weighs (1 X 1 X 12 X .283) or about 3.4 pounds.

Weight of steel

Weight of steel:- if Length of steel in meter, unit weight of steel are in kg/m – 8mm ø bar = 0.395 kg/m, 10mm ø bar = 0.617 kg/m, 12mm ø bar = 0.888 kg/m, 16mm ø bar = 1.580 kg/m, 20mm ø bar = 2.469 kg/m, and 25mm ø bar = 3.858 kg/m.

If Length of steel in feet, unit weight of steel are in kg/ft – 8mm ø bar = 0.12 kg/ft, 10mm ø bar = 0.188 kg/ft, 12mm ø bar = 0.270 kg/ft, 16mm ø bar = 0.480 kg/ft, 20mm ø bar = 0.750 kg/ft and 25mm ø bar = 1.172 kg/ft.

How much does steel weigh:- a mild steel plate or rolled steel can weigh around 7850 kg per cubic meter, or 490 pounds per cubic foot, or 0.283 pounds per cubic inch, or 40.8 pounds per square foot, or 0.283 per square inch.

Weight of steel:- weight of steel is around 7850 kg/m3 or 78.5 kN/m3 or 7.85 g/cm3 or 490 lbs/ft3 or 13231 lbs/yd3. Weight of 6mm steel is 0.222kg/m, for 8mm steel bar is 0.395kg/m, for 10mm steel bar is 0.617kg/m, for 12mm steel bar is 0.89kg/m, for 16mm steel bar is 1.58kg/m and weight of 20mm steel is 2.47kg/m.

Unit weight of steel:- unit weight of steel is defined as the ratio of weight of steel to unit volume of steel, unit weight of steel is generally measured in kg per cubic meter is 7850kg/m3, measured in kN per cubic meter is 78.5kN/m3 or measured in gram per cubic centimetre is 7.85 g/cm3, which is approximately equal in pounds per cubic feet is 490 lbs/ft3 or measured in Pounds per cubic yards is 13231 lbs/yd3.

Unit mass of steel is the ratio of weight of Steel to its per unit volume. Usually it is expressed in kilograms per cubic metre or Pounds per cubic feet. Unit mass of steel is 7850 kg/m3 (kilograms per cubic metre) or 490 lbs/ft3 (pounds per cubic feet).

Unit weight of steel
Unit weight of steel

There are different steel weight calculator for the the steel weight calculation of various size of Steel bar 8mm, 6mm, 10mm, 12mm and so more. And calculator for steel weight based on unit weight of steel and volume of round Steel bar. By this article you should calculate following

1) steel weight bar

2) formula for steel weight

3) d2/162 derivation

4) different size of Steel bar

5) 8mm steel weight per meter

6) 10 mm steel weight

7) 12mm steel weight

8) 16mm steel bar weight

9) 20mm steel weight

Unit weight of steel per meter

Unit weight of steel per meter for 6mm is 0.222kgs, for 8mm steel bar is 0.395kgs, for 10mm steel bar is 0.617kgs, for 12mm steel bar is 0.89kgs, for 16mm steel bar is 1.58kgs, for 20mm steel bar is 2.47kgs, for 25mm steel bar is 3.86kgs, for 32mm steel bar is 6.32kgs and for 40mm steel bar is 9.87kgs.

ALSO READ :-

Rod weight per bundle: 12mm, 10mm, 8mm, 16mm, 20mm & 25mm steel bar

Rod weight per piece: 12mm, 10mm, 8mm, 16mm, 20mm & 25mm steel bar

Rod weight per meter: 12mm, 10mm, 8mm, 16mm, 20mm & 25mm steel bar

Weight of number 3, 4, 5, 6, 7, 8, 9 & 10 rebar per foot

Weight of number 3, 4, 5, 6, 7, 8, 9 & 10 rebar per meter

Weight of #2, #3, #4, #5, #6, #7, #8, #9 and #10 US/ imperial rebar

Weight of 10M, 15M, 20M, 25M, 30M, 35M, 45M, 55M Canadian rebar

Unit Weight of Steel per feet

Unit weight of Steel per feet for 6mm is 0.067 kgs, for 8mm is 0.120 kgs, for 10mm is 0.188 kgs, for 12mm is 0.270 kgs, for 16mm is 0.480 kgs, for 20mm is 0.751 kgs, for 25mm is 1.174 kgs and for 32mm is 1.925 kgs.

Steel unit weight:- steel unit weight is defined as mass per unit length, if weight reinforcing bar/ rebar measured in pounds per foot known as Unit weight of rebar/steel in lb/ ft.

Unit weight of 8mm or #2.5 rebar/steel is 0.265lb/foot, for 10mm or #3 rebar/ steel, it could be 0.376lb/foot, for 12mm or #4 rebar/ steel, it could be 0.668lb/ft, for 16mm or #5 rebar/ steel, it could be 1.043lb/ft, for 20mm or #6 rebar/ steel, it could be 1.502lb/ foot, for 22mm or #7 rebar/ steel, it could be 2.044lb/ ft, for 25mm or #8 rebar/ steel, it could be 2.67lb/ foot, for 28mm or #9 rebar/ steel, it could be 3.40lb/ foot, for 32mm or #10 rebar/ steel, it could be 4.303lb/ foot and unit weight for 36mm or #11 rebar/ steel, it could be 5.313lb/foot.

Unit weight of steel/ rod/ rebar/ steel bar/ reinforcement bar

In india, in all states, Maharashtra, Telangana Karnataka, Tamilnadu, West Bengal, and major cities Delhi, Mumbai, Kolkata, Hyderabad, Chennai, Bengaluru, there is a different size of Steel bar manufactured by various company and supply and distribution of steel bar/tmt bar/rebar/steel rod size like 6mm, 8mm, 10mm, 12mm, 16mm, 20mm, 25mm, 32mm, 40mm, etc.

Unit Weight of steel is defined as ratio of weight of steel to its unit volume, weight of Steel measured in kilogram (kg) and its volume is measured in cubic metre (m3), then its unit weight = unit mass/unit volume, represented as W = m/V, where W is Steel unit weights, m for mass and V for volume, it is also known as specific weight of steel or density of steel and their SI unit is kilogram per cubic metre (kg/m3). Steel is most used element in civil engineering for structural construction, after knowing the Steel Unit Weight, it is easy to calculate amount of Steel required for projects.

Generally, when its measured in kg/m3, its unit weight in kg per cubic meter (kg/m3) is around 7850kg, when its measured in g/cm3, its unit weight in gram per cubic centimeter (g/cm3) is around 7.850 gram, when its measured in kN/m3, its unit weight in kilo Newton per cubic meter (kN/m3) is around 78.50kN, when its measured in lbs/in3, its unit weight in pounds per cubic inch (lbs/in3) is around 0.28 pounds and when its measured in lbs/ft3, its unit weight in pounds per cubic foot (lbs/ft3) is around 490.74 pounds.

The value of Unit Weight of Steel in different units

Steel Unit Weight measured in different units like kg/m3, kN/m3, g/cm3, lbs/in3 and lbs/ft3, the value of Steel Unit Weight is around 7850kg/m3, when its measured in Kilogram per cubic metre, 78.50kN/m3, when its measured in kilonewton per cubic metre, 7.850g/cm3, when its measured in gram per cubic centimetre,0.28lbs/in3, when its measured in pounds per cubic inch and 490.059lbs/ft3, when its measured in Pounds per cubic foot.

ALSO READ :-

Rod weight per bundle: 12mm, 10mm, 8mm, 16mm, 20mm & 25mm steel bar

Rod weight per piece: 12mm, 10mm, 8mm, 16mm, 20mm & 25mm steel bar

Rod weight per meter: 12mm, 10mm, 8mm, 16mm, 20mm & 25mm steel bar

Weight of number 3, 4, 5, 6, 7, 8, 9 & 10 rebar per foot

Weight of number 3, 4, 5, 6, 7, 8, 9 & 10 rebar per meter

Weight of #2, #3, #4, #5, #6, #7, #8, #9 and #10 US/ imperial rebar

Weight of 10M, 15M, 20M, 25M, 30M, 35M, 45M, 55M Canadian rebar

Unit Weight of Steel formula

In india, Steel unit weight is calculated in kilogram per metre (kg/m) and kilogram per foot kg/ft, in US imperial system and EN members of states, it is measured in Pounds per foot (lbs/ft) and Pounds per cubic inch (lbs/in).

Weight of steel bars formula:- there are two formula D^2L/162 and D^2L/533 are used for unit weight of Steel per unit length. D^2L/162, this formula are used for calculate its weight of steel bars in kg per metre (kg/m) and D^2L/533, this formula are used for calculate its weight of steel bars in kg per foot (kg/ft).

For example, calculate Steel Unit Weight of 10mm Steel bar in Kilogram per metre and kilogram per foot.

10mm steel bar weight in kg per meter, given diameter of Steel bar 10mm, length of Steel is 1 metre, then put all value in D^2L/162 formula, weight = (10×10×1)/162 = 0.617kg/m, this is 10mm Steel bar weight in kg per meter.

10mm steel bar weight in kg per foot, given diameter of Steel bar 10mm, length of Steel is 1 foot, then put all value in D^2L/533 formula, weight = (10×10×1)/533 = 0.188kg/ft, this is 10mm Steel bar weight in kg per foot.

How to calculate Steel rod weight

As we know there is a different shape of Steel rod available in market round/circular solid bar, square shaped steel rod, hexagonal bar, etc, steel is most important construction material used in building construction, now question is arises that “how to calculate Steel rod weight”, after knowing the Steel rod weight, it is easy to calculate amount of Steel required for any projects like industrial building construction, high rise building, low rise building, Bridge, dams, schools, hospitals, commercial buildings, etc.

To calculate the weight of Steel bar or rod we are using some formula, which are very helpful for site engineer, supervisor and common people.

Weight of Steel bars formula

To calculate the weight of Steel bars or rod formula are following:-

● for round/circular solid bar – Diamm2 × 0.006165, when it measured in kilogram per metre (kg/m).

● for round/circular solid bar – Diamm2 × 0.004143, when it measured in pounds per foot (lbs/ft).

● for hexagonal solid bar – sizemm2 × 0.006798, when it measured in kilogram per metre (kg/m).

● for hexagonal solid bar – sizemm2 × 0.006165, when it measured in pounds per foot (lbs/ft).

● for square shaped solid bar – sizemm2 × 0.00785, when it measured in kilogram per metre (kg/m).

● for square shaped solid bar – sizemm2 × 0.00527, when it measured in pounds per foot (lbs/ft).

Unit Weight of 6mm Steel bar/ rod/reinforcement

This is very thin steel bar sized, not used for any structural work, it is only used as wire bar, it is too thin, that known as pencil rod.

Round/circular Steel bar measured in different units, unit weight of 6mm Steel bar measured in Kilogram per meter (kg/m) is around 0.22kg, when its measured in Kilogram per foot (kg/ft), then their weight should be approx 0.067kg, when its measured in pounds per foot (lbs/ft), then their weight should be approx 0.1478 pounds and when its measured in pounds per inch (lbs/inch), their weight should be approx 0.0123 pounds.

Unit Weight of 8mm Steel bar/ rod/reinforcement bar/rebar

This is thin steel bar sized, it is used as distribution bar in roof casting and lintel beam, it is not suitable for RCC work of beam and column.

Round/circular Steel bar measured in different units, unit weight of 8mm Steel bar/rod/rebar measured in Kilogram per meter (kg/m) is around 0.390kg, when its measured in Kilogram per foot (kg/ft), then their weight should be approx 0.12kg, when its measured in pounds per foot (lbs/ft), then their weight should be approx 0.262 pounds and when its measured in pounds per inch (lbs/inch), their weight should be approx 0.0218 pounds.

Unit Weight of 10mm Steel bar/ rod/reinforcement bar/rebar

This is medium steel bar sized, it is used as main bar or distribution bar in roof casting and lintel beam, it is not suitable for RCC work of beam and column.

Round/circular Steel bar measured in different units, unit weight of 10mm Steel bar/rod/rebar measured in Kilogram per meter (kg/m) is around 0.617kg, when its measured in Kilogram per foot (kg/ft), then their weight should be approx 0.188kg, when its measured in pounds per foot (lbs/ft), then their weight should be approx 0.414 pounds and when its measured in pounds per inch (lbs/inch), their weight should be approx 0.0345 pounds.

Unit Weight of 12mm Steel bar/ rod/reinforcement bar/rebar

This is steel bar sized, it is used as distribution bar in roof casting and lintel beam, it is minimum bar size required for RCC work of beam and column.

Round/circular Steel bar measured in different units, unit weight of 12mm Steel bar/rod/rebar measured in Kilogram per meter (kg/m) is around 0.889kg, when its measured in Kilogram per foot (kg/ft), then their weight should be approx 0.271kg, when its measured in pounds per foot (lbs/ft), then their weight should be approx 0.597 pounds and when its measured in pounds per inch (lbs/inch), their weight should be approx 0.04978 pounds.

Unit Weight of 16mm Steel bar/ rod/reinforcement bar/rebar

16mm Steel bar used in all type of RCC structural work of design structure of beam, column, Foundation and slab.

Round/circular Steel bar measured in different units, unit weight of 16mm Steel bar/rod/rebar measured in Kilogram per meter (kg/m) is around 1.58kg, when its measured in Kilogram per foot (kg/ft), then their weight should be approx 0.482kg, when its measured in pounds per foot (lbs/ft), then their weight should be approx 1.061 pounds and when its measured in pounds per inch (lbs/inch), their weight should be approx 0.0884 pounds.

Unit Weight of 20mm Steel bar/ rod/reinforcement bar/rebar

20mm Steel bar used in all type of RCC structural work of design structure of beam, column, Foundation and slab.

Round/circular Steel bar measured in different units, unit weight of 20mm Steel bar/rod/rebar measured in Kilogram per meter (kg/m) is around 2.469kg, when its measured in Kilogram per foot (kg/ft), then their weight should be approx 0.752kg, when its measured in pounds per foot (lbs/ft), then their weight should be approx 1.659 pounds and when its measured in pounds per inch (lbs/inch), their weight should be approx 0.138 pounds.

Unit Weight of 25mm Steel bar/ rod/reinforcement bar/rebar

25mm Steel bar used in all type of RCC structural work of design structure of beam, column, Foundation and slab.

Round/circular Steel bar measured in different units, unit weight of 25mm Steel bar/rod/rebar measured in Kilogram per meter (kg/m) is around 3.858kg, when its measured in Kilogram per foot (kg/ft), then their weight should be approx 1.176kg, when its measured in pounds per foot (lbs/ft), then their weight should be approx 2.592 pounds and when its measured in pounds per inch (lbs/inch), their weight should be approx 0.216 pounds.

Unit Weight of 32mm Steel bar/ rod/reinforcement bar/rebar

32mm Steel bar used in all type of RCC structural work of design structure of beam, column, Foundation and slab.

Round/circular Steel bar measured in different units, unit weight of 32mm Steel bar/rod/rebar measured in Kilogram per meter (kg/m) is around 6.32kg, when its measured in Kilogram per foot (kg/ft), then their weight should be approx 1.926kg, when its measured in pounds per foot (lbs/ft), then their weight should be approx 4.25 pounds and when its measured in pounds per inch (lbs/inch), their weight should be approx 0.354 pounds.

What is admixture of concrete and it types

Why need calculation of unit weight of steel rods

You know that  Steel bar have length 12 metre of different size like 8 mm, 10 mm, 12 mm, 16 mm, 20 mm, 25 mm, 32 mm, 40 mm, 45 mm and 50 mm size.  so we have to convert length of Steel bar in weight in kilogram.

"<yoastmark
Steel bar
"<yoastmark
Steel bar

uses of steel bar

you know that Steel bar used  in building construction work and civil engineering like formation of dam, culvert ,Bridge formation, pillar formation etc.

"<yoastmark
Steel bar

size of Steel bar

There are different size of Steel bar like 6mm, 8mm, 10mm, 12mm, 16mm ,20mm 25mm and so more where 6,8,10,12,16 diameter of round bar and question asking one bundle have how many bar and number of Steel bar in one bundle are following

Dia.       Number  Length

8mm—–10nos—–12m

10mm—-7nos——–12m

12mm—-5nos ——–12m

16mm——3nos—–12m

20mm——2nos——12m

25mm——1nos——12m

32mm——1nos——12m

40mm——-1nos—–12m

45mm——1nos——12m

50mm——1nos——12m

"<yoastmark

"<yoastmark
Steel weight calculation formula

how to calculate unit weight of steel rods

Unit weight of steel rods is calculated in two unit 1) steel weight per meter in kg and 2) steel weight per foot in Kg. there is a unique formula and easy calculation of different size of Steel bar having length 12 metres. Formula for steel weight is following:

Steel weight calculation formula is  two types -steel weight per metre in kg and steel weight per foot in kg

Formula for steel weight per metre in kg is following:

steel weight =(Dia)*2/162×Length
W =( D)*2 L/162 kg

And formula for steel weight per foot in kg is following

steel weight =(Dia)*2/533×Length
W =( D)*2 L/533 kg

ALSO READ :-

Rod weight per bundle: 12mm, 10mm, 8mm, 16mm, 20mm &#038; 25mm steel bar

Rod weight per piece: 12mm, 10mm, 8mm, 16mm, 20mm &#038; 25mm steel bar

Rod weight per meter: 12mm, 10mm, 8mm, 16mm, 20mm &#038; 25mm steel bar

Weight of number 3, 4, 5, 6, 7, 8, 9 &#038; 10 rebar per foot

Weight of number 3, 4, 5, 6, 7, 8, 9 &#038; 10 rebar per meter

Weight of #2, #3, #4, #5, #6, #7, #8, #9 and #10 US/ imperial rebar

Weight of 10M, 15M, 20M, 25M, 30M, 35M, 45M, 55M Canadian rebar

1 foot steel mass/ weight:- 1 foot of 6mm steel weight around is 0.067 kgs, 8mm is 0.120 kgs, 10mm is 0.188 kgs, 12mm is 0.270 kgs, 16mm is 0.480 kgs, 20mm is 0.751 kgs, 25mm is 1.174 kgs and 32mm is 1.925 kgs.

Formula for Steel weight per metre or per foot in kg is used for calculation of Unit Weight of Steel. For example unit weight of 8 mm steel per meter or per foot in kg –

8 mm steel weight per meter = (8×8)/162 kg/m

Unit weight of 8mm steel = 0.395 kg/m

Unit weight of 8 mm steel = (8×8)/533 kg/ft

Unit weight of 8 mm steel = 0.12 kg/ft

Unit weight of 8mm Steel per meter is 0.395 kg/m and per foot is 0.12 kg/foot

"<yoastmarkHow to calculate material required for roof cast of 1800 square feet building

How to calculate material required for roof cast of 1000 square feet build

d2/162 formula derivation for steel unit weight per meter

We have to calculate unit weight of Steel rods in Kilogram per metre and we know that unit weight of steel bar is 7850 kg/m3. Its means 7850 kg is steel weight of 1 cubic metre.

To derive D^2/162

We know weight of steel = volume of steel × steel density and volume = cross sectional area× Length, so weight of steel = cross sectional area × Length × density

Steel weight formula = πD*2/ 4 × L × density, where w = weight of steel,  π = 3.14, D = diameter of Steel bar in mm, L= length of Steel bar =1m and density = 7850 kg/ m3.

Putting all the value we get weight = 3.14 × Dmm*2/4 × 1m × 7850 kg/m3, now we have to convert millimetre square into metre square, 1mm^2 = 1/1000m×1/1000m =1/1000000m^2

Calculating this we get weight = 3.14 × D m2/4000000 × 1m × 7850 kg/m3, such as weight = D*2 × 26649/4000000 kg, so weight of steel = D^2 × 0.006162 kg and it can be written as follow weight= D*2/1/0.006162 kg, when we divide 1/0.006162 we get 162 so final weight of steel bars formula kg per metre is weight =D*2 ×L/162 kg/m is derived.

Hence steel unit weight formula for kg per meter is weight =D*2 ×L/162 kg/m

d2/533 formula derivation for steel unit weight per foot

We know weight of steel = volume × density, such as w = πD*2/4× L× density, proceed w = 3.14 × Dmm*2/4 × 1ft × 222 kg/ ft3.

As 1mm*2 = 1/ 304.80 × 304.80 ft*2, hence w = (3.14 × Dft × 1ft/ 4 × 304.80 × 304.80) × 222kg/ft3, solving you get w = D*2 × 0.001878 kg/ foot, so weight = D*2/1/0.001878 kg/ foot, hence weight = D^2/ 533 × L kg/ ft formula derived. This formula is used for steel weight calculation per foot.

Steel weight per foot:- weight of steel per foot for 6mm is 0.067 kgs, 8mm is 0.120 kgs, 10mm is 0.188 kgs, 12mm is 0.270 kgs, 16mm is 0.480 kgs, 20mm is 0.751 kgs, 25mm is 1.174 kgs and 32mm is 1.925 kgs

8mm steel weight per meter

● find the 8 mm steel weight per meter and length 12 metre and 10 number of Steel in one bundle:-

 calculate the weight of 8 mm Steel bar
Calculate the weight of Steel bar
8mm steel bar

● weight =D2×L/162

1) 8 mm steel weight per meter

Weight=8×8×1÷162=0.39kg

2)  8 mm steel weight for 12m

W=8×8×12÷162=4.74kg

3) 8 mm steel weight for 1bundle

=8×8×12×10÷162=47.407kg

0.39 kg is Unit weight of 8 mm steel per metre,4.74 kg is for 12 meter and 47.407 kg is for 1 bundle 8 mm steel.

 10 mm steel rods weight per meter

● how to calculate weight of 10 mm size Steel bar having 12 metre length and 7 number of Steel in one bundle:-

How to calculate weight of 10 mm Steel bar
Calculate the weight of Steel bar
10mm steel bar

●weight calculation:-

1) 10 mm steel rods weight for 1m =10×10×1÷162=0.617 kg

2) 10 mm steel rods weight for 12m W=10×10×12÷162=7.407kg

3) 10 mm steel rod weight for 1bundle =10×10×12×7÷162=51.85kg

0.617 kg is Unit weight of 10 mm steel per metre,7.407 kg is for 12 meter and 51.85 kg is for 1 bundle 10 mm steel.

12mm steel bar weight per meter

● how to calculate 12mm steel bar weight having length 12 metre and 5 number of steel bar in one bundle:-



Calculate the weight of 12 mm Steel bar
Calculate the weight of Steel bar

● weight calculation:-

1) 12mm steel bar weight for 1m =12×12×1÷162=0.889kg

2)  12mm steel bar weight for 12m =12×12×12÷162=10.667 kg

3)  12mm steel bar weight for1bundle

=12×12×12×5÷162=53.333kg

0.889 kg is Unit weight of 12 mm steel per metre,10.667 kg is for 12 meter and 53.34 kg is for 1 bundle 8 mm steel.

16mm steel bar weight

how to calculate weight of size of 16 mm Steel bar having 12 m length and 3 number of steel bar in one bundle

Calculate the weight of 16 mm Steel bar
Calculate the weight of Steel bar

● weight calculation:-

1) 16mm steel bar weight for 1m W=16×16×1÷162=1.58kg

2)  16mm steel bar weight for 12m W=16×16×12÷162=18.96kg

3)  16mm steel bar weight for 1 bundle

=16×16×12×3÷162=56.889kg

1.58 kg is Unit weight of 16 mm steel per metre,18.96 kg is for 12 meter and 56.889 kg is for 1 bundle 16 mm steel.

20mm steel weight

how to calculate weight  of size of 20 mm Steel bar having length 12 metre and 2 number of steel bar in one bundle:-

Calculate the weight of 20 mm Steel bar
Calculate the weight of Steel bar

● weight calculation:-

1) 20mm steel weight for 1m  W =20×20×1÷162=2.469kg

2)  20mm steel weight for 12m W=20×20×12÷162=29.629kg

3)  20mm steel weight for 1 bundle =20×20×12×2÷162=59.259kg

2.469 kg is Unit weight of 20 mm steel per metre,29.629 kg is for 12 meter and 59.259 kg is for 1 bundle 20 mm steel.

25mm steel rod weight

how to calculate weight of Steel bar of size 25 mm having length 12 metre:-

Weight of 25 mm Steel bar
Calculate the weight of Steel bar

● weight calculation:-

1) 25mm steel rod weight for 1m W=25×25×1÷162=3.858kg

2) 25mm steel rod weight for 12m W=25×25×12÷162=46.296kg

32mm steel rod weight

● how to calculate weight of 32 mm size of Steel bar having length 12 metre:-

Calculate the weight of 32 mm Steel bar
Calculate the weight of Steel bar

● weight calculation:-

1) for 1m W=32×32×1÷162=6.32kg

2) for 12m W=32×32×12÷162=75.85kg

40mm steel rod weight

●Example 8:-● how to calculate weight of Steel bar size of 40 mm having length 12 metre:-

Calculate the weight of 40 mm Steel bar
Calculate the weight of Steel bar

● weight calculation:-

1) for 1m W=40×40×1÷162=9.876kg

2) for 12 m W=40×40×12÷162=118.518kg

●Example 9

● how to calculate weight of Steel bar of size 45 mm having length 12 metre

● weight calculation:-

1) for 1m W=45×45×1÷162=12.5kg

2) for 12m W= 45×45×12÷162=150kg

●Example 10

● how to calculate weight of Steel bar size 50 mm having length 12 metre

● weight calculation:-

1) for 1m W =50×50×1÷162=15.432kg

2) for 12m W=50×50×12÷162=185.185kg

How to calculate weight of different size of Steel bar  in Kilogram per foot (Kg/foot)

● in foot calculation and unit weight of steel in kg/ft

formula of weight =D*2/533×L

Kg/Foot

●Note:-

D= diameter of Steel bar in millimetre
L= length of Steel bar in foot=39 foot
Density= 222 kg/ft3

d2/533 derivation

Weight=Volume×density

W=πD*2/4×L×density
W=3.14×Dmm*2/4×1ft×222kg/ft3
1mm*2.  =1/304.80×304.80 ft*2

W=(3.14×Dft×1ft/4×304.80×304.80)×222kg/ft3

W = D*2 ×0.001878 kg/foot

Weight=D*2/1/0.001878 kg/foot

Weight =D*2/533 ×L kg/ft

●Example 1:-

● how to calculate weight of Steel bar of 8 mm size having length 39 foot and 10 number of steel bar in one bundle-

Calculate weight of 8 mm Steel bar kg/ft
Calculate the weight of Steel bar

● weight calculation:-

1) for 1foot

W=8×8×1÷533=0.12 kg

2) for 39 ft W=8×8×39÷533=4.68kg

3) for 1 bundle W= 8×8×39×10÷533=46.80 kg

●Example2

● how to calculate weight of Steel bar having size 10 mm and 39 feet long having 7 number of steel bar in one bundle

●solve:-

1) for 1foot W=10×10×1÷533=0.1876kg

2) for 39 feet W=10×10×39÷533=7.317kg

3)for 1bundle W=10×10×39×7÷533=51.219kg

●Example3

● how to calculate weight  of Steel bar having size 12 mm and 39 feet long and 5 number of steel bar in one bundle:-

● solve:-

1) For 1foot W=12×12×1÷533=0.270kg

2) For 39 feet W= 12×12×39÷533=10.53 kg

3) For 1 bundle W=12×12×39×5÷533=52.68kg

●Example 4

how to calculate weight of Steel bar 16 mm size having length 39 feet and 3 number of steel bar present in one bundle

●solve:-

1) for 1foot W=16×16×1÷533=0.80kg

2) for 39 feet W=16×16×39÷533=18.73kg

3) for 1bundle W=16×16×39×3÷533=56.195kg

●Example5

● how to calculate the weight of Steel bar size 20 mm having length 39 feet and 2 piece of Steel bar in one bundle

●Solve :-

1) for 1foot W=20×20×1÷533=0.75 kg

2) for 39 feet W=20×20×39÷533=29.268kg

3) for 1bundle W=20×20×39×2÷533=58.536kg

●Now your turn:- any quiry , questions about this topics calculation of different size of Steel bar, please 🙂🙂comment share and ask questions, your questions are welcome 🙏in this blog

● thanks for joining us🙂🙂

Now you can follow me on on Facebook and subscribe my youtubechannel

Conclusions:-

Steel weighs around 7850 kg/m3, or 78.5 kN/m3, or 7.85 g/cm^3, or 490 pound per cubic foot, or 13231 pound per cubic yard, or which is approximately equal as 0.2833 pound per cubic inch. This is unit weight of steel.

Weight of steel:- if Length of steel in meter, unit weight of steel are in kg/m – 8mm ø bar = 0.395 kg/m, 10mm ø bar = 0.617 kg/m, 12mm ø bar = 0.888 kg/m, 16mm ø bar = 1.580 kg/m, 20mm ø bar = 2.469 kg/m, and 25mm ø bar = 3.858 kg/m.

If Length of steel in feet, unit weight of steel are in kg/ft – 8mm ø bar = 0.12 kg/ft, 10mm ø bar = 0.188 kg/ft, 12mm ø bar = 0.270 kg/ft, 16mm ø bar = 0.480 kg/ft, 20mm ø bar = 0.750 kg/ft and 25mm ø bar = 1.172 kg/ft.



3 thoughts on “Steel weight and formula for unit weight of steel calculation”

    • Hello sir good morning I want to take me knowledge in steel member name footing, column, beam and cantilever beam and building pictures and slab steel binding please help me sir steel work knowledge

      Reply
  1. Hello sir good morning I want to take me knowledge in steel member name footing, column, beam and cantilever beam and building pictures and slab steel binding please help me sir steel work knowledge

    Reply

Leave a Comment
