What is the weight of brick wall per sq ft and sq m

What is the weight of brick wall per sq ft and sq m | weight of brick wall per square foot | weight of brick wall per cubic metre | weight of brick wall per square meter | weight of brick wall per cubic foot.

What is the weight of brick wall per sq ft and sq m
What is the weight of brick wall per sq ft and sq m

Common red brick use to form exterior and interior wall in residential and commercial building which is load bearing or non – load bearing structure. Bricks are put on series, laid one above other by using Adhesive for binding material cement mortar, made of mixing of cement, sand and water in required proportion.

◆You Can Follow me on Facebook and Subscribe our Youtube Channel

You should also visits:-

1)what is concrete and its types and properties

2) concrete quantity calculation for staircase and its formula

Where is two types of Greek word formation in house one is full brick wall and second one is half brick wall, full brick wall will be 9 inch thick and half sizes will be 4 inch thick.

Unit Weight of brick wall in kN/m3

Generally for 9 inch or 4 inch thick brick wall, density or Unit Weight of brick wall will be ranging from 1800 to 2000 kg/m3 or 18 to 20 kN/m3, when combined with cement mortar.

Weight of brick wall 9″ or 4″

To calculate the weight of brick wall, we should multiply the volume and density of brick, considering brick wall height is 1 meter of 230mm thick and their length is 1 meter, here density of brick wall is 1900 kg/m3. Weight of brick wall = volume × density.

To calculate weight of 230mm or 9 inches thick brick wall per square meter by using given formula, weight of brick wall = volume × density, we get volume = 1 × 1 × 0.230 = 0.230m3, density = 1900kg/m3, weight of brick wall = 0.230m3 × 1900kg/m3 = 437 kg, therefore weight of 9 inch thick brick wall per square metre is about 440kg.

To calculate weight of 100mm or 4 inches thick brick wall per square meter by using given formula, weight of brick wall = volume × density, we get volume = 1 × 1 × 0.100 = 0.100m3, density = 1900kg/m3, weight of brick wall = 0.100m3 × 1900kg/m3 = 190 kg, therefore weight of 4 inch thick brick wall per square metre is about 190kg.

Weight of brick wall per cubic meter

To calculate weight of 9 inch or 4 inches thick brick wall per cubic meter by using given formula, weight of brick wall = volume × density, we have volume = 1 m3, density = 1900kg/m3, weight of brick wall = 1m3 × 1900kg/m3 = 1900 kg, therefore weight of 4 inch or 9 inch thick brick wall per cubic metre is about 1900kg.

Weight of brick wall per square meter

Generally, weight of brick wall per square metre is ranging between 190 kg to 440 kg or 420 lbs to 970 lbs. For 230mm or 9 inch brick wall, their weight should be 440 kg or 970lbs per square meter and for For 100mm or 4 inch brick wall, their weight should be 190 kg or 420 lbs per square meter.

◆You Can Follow me on Facebook and

Subscribe our Youtube Channel

Weight of brick wall per square foot

We know 1m2 = 10.764 sq ft, 10.764 sq ft brick weight = 440kg, then 1 sq ft = 440kg/10.764 = 41kg for 9 inch wall and 1 sq ft = 190kg/10.764 = 18kg for 4 inch wall, Generally, weight of brick wall per square foot is ranging between 18 kg to 41 kg or 40 lbs to 90 lbs. For 230mm or 9 inch brick wall, their weight should be 41 kg or 90lbs per square foot and for For 100mm or 4 inch brick wall, their weight should be 18 kg or 40 lbs per square foot.

ALSO READ :-

Cement required for 1 sqm half brickwork

6 inch brick wall calculation and their estimate

How to calculate quantity of bricks | brick calculation formula

How many bricks do I need to build a normal house

Brick calculation formula | how to calculate Brick in a wall

Weight of brick wall per cubic foot

To calculate weight of 9 inch or 4 inches thick brick wall per cubic foot by using given formula, weight of brick wall = volume × density, we have volume = 1 ft3, density = 54kg/ft3, weight of brick wall = 1 ft3 × 54kg/ft3 = 54 kg, therefore weight of 4 inch or 9 inch thick brick wall per cubic foot is about 54kg.
